CL237 Corner Hinge, Lift-Off Removable Hinge, 90° Opening, Zinc Alloy, Sand Blasted Finish
The CL237 corner hinge is designed for easy removal and access in industrial and enclosure applications. Featuring a durable zinc alloy construction with a stainless steel rotating shaft, this hinge allows for a 90° opening angle, providing efficient space management and door removal capabilities. Ideal for use in environments where doors or panels need frequent access or replacement.
Material
- Fixed Hinge: Zinc alloy
- Rotating Shaft: SUS316 Stainless Steel
- Pin: Steel
Surface Finish
- Fixed Hinge: Sand Blasted
- Rotating Hinge: Chrome Plated
Color/Appearance
Matte gray with sand-blasted finish
Products Categories
Get A Free Quote
Key Features
- 90° opening angle for easy door removal and reinstallation
- Durable zinc alloy construction with stainless steel rotating shaft
- Designed for heavy-duty use in industrial applications
- Easily removable for maintenance and accessibility
Specifications
- Maximum Static Load (Radial): 228N
- Maximum Static Load (Axial): 290N
- Opening Angle: 90°
- Compatible Fasteners: M4 countersunk screws (not included)
Applications
- Industrial enclosures
- Control panels
- Electrical cabinets requiring easy door removal
Keywords
Corner hinge, removable hinge, lift-off hinge, CL237, zinc alloy hinge, industrial hinge, 90° door hinge, alternative, lift-off access hinge, sand-blasted hinge
