MS784 Cam Latch with Plastic Handle – 90° Rotation, Black Finish, High Durability
The MS784 cam latch provides a secure and efficient locking mechanism suitable for industrial and commercial applications. Its 90° rotational handle allows smooth and precise operation for opening and closing. Designed with a black plastic handle and durable zinc alloy base, the MS784 ensures high wear resistance and long-lasting performance. With a maximum static load of 270 N, this cam latch is ideal for control panels, machinery enclosures, and access doors.
Material:
- Base and Handle: Zinc alloy base, plastic handle (black)
- Components: Steel cam and carbon steel hex nut
-
Surface Finish and Appearance:
- Handle: Black plastic, offering an ergonomic grip and modern appearance.
- Base: Zinc-plated surface for enhanced corrosion resistance.
- Cam: Hardened steel with a bright zinc finish for durability.
Products Categories
Get A Free Quote
Key Features
- 90° Rotation Mechanism: Enables secure and precise locking and unlocking operations.
- Black Plastic Handle: Ergonomic design providing excellent grip and resistance to wear.
- High Load Capacity: Withstands a static load of up to 270 N, suitable for heavy-duty applications.
- Easy Installation: Compatible with standard cut-outs, simplifying the installation process.
- Durable Construction: Zinc alloy base and steel components ensure long-lasting performance.
Specifications
- Max Static Load Capacity: 270 N
- Max Input Torque: 20 N·m
- Recommended Nut Tightening Torque: 20 N·m
- Latch Dimensions:
- Handle Diameter: Ø40 mm
- Overall Height: 25.3 mm
- Cut-Out Dimensions:
- Square: 22.5 x 22.5 mm
Applications
- Suitable for electrical control panels, industrial machinery enclosures, and access doors in commercial environments.
Keywords
MS784 latch, cam lock, durable handle, black plastic grip, 90° rotation mechanism, high-performance latch.
