Product Name: DK616 Adjustable Over-Center Lever Latch with Key Lock
The DK616 lever latch is designed for industrial-grade applications, offering an adjustable over-center action for secure and precise closure. Constructed from zinc alloy and polished with an elegant chrome finish, this latch ensures durability, corrosion resistance, and professional appearance. The key-locking mechanism (default K030 key) provides enhanced security, making it ideal for heavy-duty enclosures and equipment.
Material:
- Base and Handle: Zinc Alloy
- Keeper: Stainless Steel
-
Surface Finish and Color/Appearance:
- Chrome-plated for a polished, corrosion-resistant finish.
Products Categories
Get A Free Quote
Key Features
- Adjustable Grip Range: Allows fine-tuning between 45-55mm for precise alignment and closure.
- Heavy-Duty Load: Rated for up to 910N of static load, suitable for industrial applications.
- Key-Locking Mechanism: Equipped with a default K030 key for enhanced security.
- Durable and Corrosion-Resistant: Zinc alloy and stainless steel construction with a chrome finish ensures longevity and professional appearance.
- Ergonomic Lever: Simplifies operation and provides built-in leverage to handle stuck doors or panels.
Specifications
- Maximum Static Load: 910N
- Grip Adjustment Range: 45-55mm
- Dimensions:
- Overall Length: 160mm
- Mounting Hole Diameter: Ø5mm
- Mounting Hole Spacing: 100mm (length) x 31mm (width)
- Installation: Designed for M5 screws or rivets.
Applications
- Industrial ovens and machinery enclosures
- Refrigeration and cold storage units
- Automotive and marine compartments
- Toolboxes and commercial equipment
Keywords and Comparable Part Numbers
- DK616 latch
- Adjustable lever latch
- Zinc alloy compression latch
- Chrome-plated key-locking latch
- Comparable part numbers: CT1338, A7-10-3TL, A2-10-501-21
